Industrial Biomass Pellet Burner

Scan the QR code
The Industrial Biomass Pellet Burner is a highly efficient semi-gasification burner that utilizes biomass pellets, wood chips, sawdust, and other organic biomass materials as fuel.
Share to:
Introduction
Technical Parameter

wood-pellet-burner

The biomass wood pellet burner is a biomass semi-gasification automatic control burner. It is a biomass high-temperature cracking burner that uses biomass pellets, wood chips, wood powder, sawdust and other organic biomass as fuel. Biomass burner, combustion cost ratio It saves 75% of electricity, 60% of fuel, 50% of natural gas, and 40% of liquefied gas.


industrial-biomass-burner



Biomass burner features:

1. Wide range of equipment applications: Biomass burners are suitable for coating lines, electroplating factory ovens, boilers, small power station boilers, industrial kilns, incinerators, smelting furnaces, die-casting machines, drying equipment, kitchen equipment, drying equipment, Food drying equipment, ironing equipment, painting equipment, highway construction machinery and equipment, industrial annealing furnaces, fuel, gas, coal-fired large-tonnage boilers, asphalt heating equipment and other thermal energy industries.

2. Low investment and operating costs: The biomass combustion mechanism is reasonably designed, and the modification cost is low when used in various equipment. The heating cost is more than 60% lower than that of oil-fired boilers and more than 40% lower than that of gas-fired boilers. It is the best choice for electric furnaces and oil furnaces. , a good choice for energy-saving and environmentally friendly gas furnace renovation and replacement.

3. Simple operation and convenient maintenance: It adopts variable frequency automatic feeding and wind ash removal. It is simple to operate, has a small workload and can be operated by one person. The biomass burner is a good choice for the majority of boiler companies.

4. Wide source of fuel: This burner uses wood and sawdust pellets as raw materials, which has high calorific value and avoids the coking phenomenon of straw pellets.


Biomass Burner Working Video:



Technical Parameters of Biomass Pellet Burner

Biomass Pellet Burner ( Air Cooling )
model Unit BJG-300-G BJG-500-G BJG-1000-GB BJG-1500-G BJG-2000-G
Rated thermal power Kcal 200000 300000 600000 900000 1200000
 Efficiency   95%
Power consumption Kw/hr 0.75 0.95 2.6 3.4 4.4
Size

length Mm 2050 2050 2250 2760 2760
wide Mm 850 1000 1170 1390 1390
high Mm 1500 1650 1850 2180 2180
weight Kg 720 950 1370 2250 2250
Fuel consumption Kg/kr 50 75 150 225 300

Biomass Pellet Burner ( Water Cooling )
Model Unit BHJ-500-S BHJ-1000-S BHJ-2000-S BHJ-3000-S BHJ-4000-S BHJ-6000-S BHJ-8000-S
thermal power Kcal 300000 600000 1200000 1800000 2400000 3600000 4800000
Heat efficient   95%
Power consumption KW 0.95 2.6 3.75 7 8.2 15.4 30.8
Size


length Mm 2018 2185 2655 3050 3535 3865 4320
wide Mm 900 1000 1200 1410 1568 1815 2100
high Mm 1570 1765 1965 2320 2650 2780 2950
weight Kg 850 1280 1760 2640 3100 4200 5650
Fuel consumption Kg/hr 75 150 300 450 600 900 1200
